Products
Brushless Ac Induction Motors
Place of Origin:Zhejiang, China
Brand Name:JULANTE
Model Number:MS series electric motor
Type:Induction Motor
Features
Essential details
| Warranty:3months-1year Place of Origin:Zhejiang, China Brand Name:JULANTE Model Number:MS series electric motor Type:Induction Motor Frequency:50HZ Phase:Three-phase Protect Feature:Totally Enclosed AC Voltage:380V or customized Efficiency:IE 1 |
color:yellow / red /blue/customized ambient temperature:-15℃≤0≤40℃ altitude:not exceeding 1000m duty:continuous running insulation class:B/F protection class:IP44/ IP54/IP55 cooling type:IC0141 apply machines and equipments:drilling machines ,blowers , pumps and so on type:MS series electric motor brand:julante and OEM |
Packaging & delivery
Lead time:
| Quantity(pieces) | 1 - 310 | >10 |
| Lead time (days) | 10 | To be negotiated |
Product Overview
Three Phase Motor 3 Phase Ac Induction Motor is made of high quality cast iron.With optimized construction design,they can ensure the requirement
of structure rigidity and intensity.Silicon steel plate is used in stator core and rotor core,it has good insulation on surface,low loss which ensures the higher efficiency.High quality insulation material combines the perfect insulation system which makes the insulation completely without clearance,high rigidity of the winding end,it can endure switching and reversing intensity,F class insulation makes the motor with higher heat stability and longer life.
FEATURES AT A GLANCE
We use die-casting technology to ensure the stable quality of the rotor and aesthetic appearance.
The design of bearing and motor construction focuses on motor type,force on the motor,speed,lubricate type,including bearing,design of oil sea and lubricant etc.It has the advantage of credible performance and easy maintenance.For the frame size from 250 and below,we generally use closed bearing;frame size above 250 we use open type.Bearing.Regreasing can be done during running.Perfect primer ensures the motors with good apperance and the motors are durable.We can also use special corrosion protection coating.
Right elevation
Left elevation
Front elevation
PRODUCT SPECIFICATIONS
|
No
|
Item
|
Data
|
|
1
|
Brand Name
|
Julante
|
|
2
|
Power
|
0.18KW-560KW
|
|
3
|
Voltage
|
220/380/440/660V
|
|
4
|
Speed
|
750-3000R/MIN
|
|
5
|
Wire
|
100% Copper wire
|
|
6
|
Frequency
|
50/60HZ
|
|
7
|
Protection Class
|
IP44/54/55 B/F/H
|
|
8
|
Warranty
|
1Year
|
|
9
|
-Ambient Temperature
|
-15℃≤0≤40℃
|
|
10
|
Phase
|
Three Phase
|
|
11
|
Application
|
General Machinery
|
|
12
|
Mounting Type
|
B3/B5/B35
|
|
13
|
Duty
|
S1 Continuous
|
|
14
|
Place of origin
|
Zhejiang,China
|
|
15
|
Protect Feature
|
Toally Enclosed
|
|
16
|
Model Number
|
Y/Y2/YE3/YR/YZ
|
|
17
|
Efficiency
|
IE2 IE3
|
|
18
|
Certification
|
CE CCC ISO9001
|
|
19
|
Altitude
|
Not exceed 1000m
|
|
20
|
Standard
|
Confirm to IEC international standard
|
PRODUCT CONFIGURATION
Rotor
Stator
Motor Casing
Transport
FAQ
Is no-load operation of motor products feasible?
Q: Is no-load operation of motor products feasible?
A: No-load operation refers to running a motor without a load. Normally, running a motor at no load is undesirable because it wastes energy and can damage the motor.
When a motor is running at no load, it may consume too much power, which will result in a low power factor. The lower the power factor, the lower the efficiency of the motor, which means that the motor requires more energy to produce the same amount of power. In addition, no-load operation can damage the motor because the motor has no load to balance its rotational inertia, which may cause the motor to overspeed or vibrate.
Therefore, in general, motors are not allowed to run at no load for long periods of time. If no-load operation is required, it is recommended that it be done for a short period of time, otherwise damage may be caused to the motor.
What requirements should the manual of the motor product have?
1. Clear and detailed content
2. Provide operating instructions, safety warnings and maintenance points
3. Adapt to different user levels, with easy to understand
4. Contain the corresponding technical parameters and performance indicators
5. Provide installation methods and schematics
6. Troubleshooting and maintenance methods to explain
7. To ensure compliance with national standards and regulations
8. Explain the terms of the product warranty and service guarantee
9. Provide contact information and channels to facilitate user consultation
10. Ensure the accuracy of the text to avoid ambiguities and errors.
